03
170
400
70
DIM.B
277
80
GAS
Electric
MIN.650mm
MIN 435mm
MAX.880
DIM.B
Mark on the wall the hole positions as shown in diagram.
The Wall Plugs supplied are suitable for solid walls only. When xing to any other type of
wall use suitable alternative xings.
25
