04
Drill the wall, insert the plugs for all the 6 marked holes and x the screws for the top two holes of the hood.
[11] x 2
[10] x 5
2mm
[10][11]
Position the hood over the top two screw then x the bottom screws from inside the hood.
Tighten the top 2 screws to secure.
05
[11] x 1
