02
DIM.B
DIM.B
MIN.750mm
MIN 650mm
170
122
34
170
90
Gas
Electric
MAX 935
25
Mark on the kitchen wall the holes to x the cooker hood.
The Wall Plugs supplied are suitable for solid walls only. When xing to any other type of wall use
suitable alternative xings.
