CaterWil GTS3 - Page 41

41
Table 4. Lithium battery specifications
Nominal voltage
24 V
Rated capacity
42 A*h
Weight
4 kg
Working temperature
-20 … 60 °C
Charge temperature
0 … 40 °C
Storage temperature
-20 … 60 °C
Number of cycles at 40% capacity
loss
1000 cycles of full charge/discharge
Replacement and disposal of batteries should only be performed by a
qualified technician. If the battery fails, it is replaced completely.
Sequence of operations when removing or installing batteries:
1. Loosen the thumbscrews on the battery module cover and lift the
cover up. If the headlights are installed on the cover, you must
carefully disconnect the headlight power connector.
2. Disconnect the battery connector.
3. Release the battery from the holder and remove it.
