扬声器系统技术规格
FL-30A
USERS' MANUAL FOR FL35
高音
低音
01 HIGH FIDELITY SPEAKER HIGH FIDELITY SP EA KE R 04
Cautions:
1. Ensure speaker cables connection with power amplifier is firm, otherwise it will cause noise.
2. Ensure speaker should be placed in horizontal and a solid place, place the speaker at the back
facing the wall away at least 20cm distance to get stronger bass.
3. The opposite polarity connection could cause poor stereo sound.
Maintenance:
1. Please avoid the speaker overloading in a long time.
2. Please make sure set the amplifier in lower or minimum volume before switching it on.
3. Cleaning the cabinet by using the dry and soft cloth, please do not clean it with any chemical liquid,
such as gas.
Accessories：
Speaker cable.2pcs
Note: Data are subject to change without notice.
FL-30A
声学类型：倒相式2分频Vented Box 2way
高音单元: 1x1英寸铍膜球顶高音(Scan-speak 绅士宝)
低音单元: 1x6.5英寸碳纤纸盆中低音(Scan-speak 绅士宝)
灵敏度：88dB
额定阻抗：4Ω
功率范围：30-120W
频响范围：45Hz-20kHz
外形尺寸: W238xD405xH380 mm
净重: 14.5kg
KEY FEATURES:
1. FL30A box full of fine handmade qualities of santos rosewood with matte skin,
structure, unique and luxurious, filled with fashionable style.
2. Fitted with Beryllium diaphragm tweeter produced by Scan-Speak
This tweeter is“top of the range”with its pure beryllium diaphragm, large roll surround, and
AirCirC Motor system, it provide a excellent-unsurpassed sound, outstanding off-axis response,
low distortion and dynamic precision. Using Beryllium diaphragm technology enables the sound
transfer speed up to 11000m/s which is much faster than used normal material, This ensures
sound clear and clean, and with minimum distortion as well.
3. Fitted with 6.5" midwoofer produced by Scan-Speak
The Scan-Speak Revelator midwoofer is built in Patented Symmetrical Drive Motor Design, Low
Damping SBR Rubber Surround, Large Ferrite Magnet System, Low-Loss linear suspension. The
cone is built in the sliced paper cone technology. The slices are filled with damping glue, which
dramatically reduces breakup modes in the diaphragm.
4. Crossover adopting high quality copper foil inductor technology
It is with high quality copper foil inductor, which keeps internal consumption at the lowest and
minimizes eddy current distortion.
5. With best simulation by LEAP for loudspeaker systems
In order to gain the best performance, the simulation by leap is repeatedly and it helps find out the
best acoustic design for loudspeaker systems.
