CBE CB-522 - Installation Guide; Critical Safety Precautions; Charger Mounting and Ventilation; Cable and Battery Handling

Fig.1-DIMENSIONS(mm):
INSTALLATION
Fig.2-VERTICALINSTALLATION
IMPORTANT: -Theinstallationofthisdevicemustbecarriedoutbyspecializedtechnicians.
-Donotcarryoutanymaintenancewhenthebatterychargerisconnectedtothe
230Va.c.powersupplynet.
-
-Caution,donotconnectthebatterycharger:
whenageneratorsetwithnonstabilisedoutputvoltageisemployed
withpowermainsvoltageexceedingtheratedvalue(230Va.c.±10%)
-Incaseofbatterycharger’smisuse,theguaranteefallsoffandthemanufacturer
declinesallresponsibilityfordamagestopeopleandthings.
1
1
BATTERY CHARGER
CABLES
- Usecableswithappropriatesection,minimumcrosssectionarea6mm².
- Protectcablesfromanypossibledamage.
-Installthebatterychargerinanappropriatehousing,dryandventilated;maximumefficiencycanbe
obtainedwhenthebatterychargerisinstalledinverticalposition(seefigure2),keepingthefrontside
atminimumdistanceof300mmandthebottomandtopsideataminimumdistanceof100mmfrom
thehousingsides.
-Donotcoverairintakes.
- Toguaranteeaproperchangeofairtheinstallationoftwoairintakes(oneplacedonthetopandone
onthebottom,seefigure2)ensuringaworkingtemperatureinsidethehousingnotexceeding50°C.
-Makesurethatthe230Va.c.safetyswitchcanbeeasilyreached.
- Theconnectiontopowersupplymainsshallbemadeinaccordancewithnationalinstallationrules.
-Beforedisconnectingthebatterychargerfrom230Va.c.powersupply,turnthesafetyswitchoff.
- Theinstallationrequiresthefixingofno.4pinsthatcanbeeasilyplacedonthe4sides.
- ThebatterychargercanbeinstalledtogetherwithCBE12Vand230Vdistributionpanels,usingthe
appropriatemodularjoints.
BATTERY
- Lead-acidbatteriesshallbepositionedinawellventilatedplace.
- Useonly12Vd.c.rechargeableleadbatteries(capacity>40Ah).
- Donotuse"notrechargeable"batteries.
- Exhaustedbatteriesshallbedisposedinaccordancewithexistingenvironmentalprotection
regulations.
Warning:
7
ENGLISH
180
190
85
160
110
197
207
