CBE DS-520AN User Manual

13
MAINPARTSOFTHEELECTRICALSYSTEM
GB
u
u
u
u
u
u
u
u
u
u
CONTROLPANEL-“PC-200T4tIH”mains’control,batterytest,tanktest,temperaturetestandclockfunction.
12VDISTRIBUTIONBOX“DS-520AN -mainrelais,batteryparallelrelais(12V-70A),fridgerelais,pumprelais,car
batteryrechargingdevice,amperemeter, protectionfuses.
LEISUREBATTERY“B2”-itgivespowertoalltheusers
CARBATTERY“B1”
230VCUT-OUTboard-itpowersandprotectsallthe230Vusers
“
BATTERYCHARGER-buffer-systembatterycharger.
ELECTRONICTANKPROBE-itmeasuresthecontentofthewatertanks,visualizationin“%”.
TANKPROBEWITHSCREWS“SS/P”-signalizationoffullwastewatertank
ENGINEALTERNATOR-itrechargesinparallelboththecarandtheleisurebattery
“50A”CAR(B1)ANDLEISURE(B2)BATTERYPROTECTIONFUSES
IMPORTANT
BATTERIES
BATTERYCHARGER
TANKPROBES
FUSES
w
w
w
w
w
w
w
w
Maintenanceinterventionsontheelectricplantshallbecarriedoutbyspecializedpersonnel.
Beforecarryingoutmaintenancesworksdisconnectthebatteryandthepowersupplyline.
Theacidkeptinthebatteriesispoisoningandcorrosive. Avoidanycontactwithskinandeyes.
Ifthebatteryiscompletelydischargeditneedsrechargingforalmost10hours.Ifdischargedformore
than8weeksitmaybedamaged.
Checkperiodicallytheleveloftheliquidofthebattery(withacid);theGEL batterydoesnotneedany
maintenancebutacountinuousrecharging.
Incaseofalongerstoptheservicesbatteryhastobeconnectedorrechargedregularly.
Thebatterychargermustbeinstalledinadryandventilatedplace.
Thisdeviceshallbeinstalledbyspecializedtechniciansonly.
Intheevent ofbatterycharger’smisuse,theguaranteeshallnolongerbevalid andthemanufacturer
declinesallresponsibilityfordamagestopeopleandthings.
Donotcarryoutanymaintenancewhenthebatterychargerisconnectedtothe230Vpowersupply
net.
Donotcoverairintakesandassureanappropriateventilation.
Beforedisconnectingthebatterychargerfrom230Vpowersupply,turnthesafetyswitchoff.
Replacethefusesonlyafterfindingouttherealcauseofthedamageonly.
Ifthefusesarereplacedobservethevalueoftheamperageestablished.
w
w
w
w
w
w
w
w
w
w
Checkthecorrecttighteningoftheconnectionbindingscrewandbrushofftheoxyde.
Iftheleisurebatteryisremoved,isolatethepositivepole(inordertoavoidshort-circuitsduringan
accidentalcarenginestarting).
Neverletwaterinthetanksforlongtime,inordertoavoidfoulings,especiallyinthewastewatertank.
230VCUT-OUTBOX
w
w
w
w
w
Beforetakingawaythecover,checkifthe230Vsocketisdisconnected.
Inordertoavoidanydamagetothebox,checkthecorrecttighteningoftheconnections.
Inordertocutpowertothewhole230Vsystem,pleasetakecarethatthe230Vmainswitchmustbe
onthe“0”(OFF)position.
Connectanddisconnecttheexternal230Vnetonlywhenthemainswitchisoff.
Incaseofautomaticswitchbreak,findthedamagebeforegivingpoweragaintotheelectrical
system.
Readwithcarethemaintenanceanduseinstructionsprovidedbythemanufacturer.
ADVICEANDCHECKS
ENGLISH
