CBE DS-520AN User Manual

14
CONTROLPANEL“PC-200T4tIH”
1)
3)
4)
5)
6)
7)
9)
10)
11)
12)
13)
14)
15)
16)
17)
Testbuttontocheckthelevelin%ofthedrinkandwastewatertank
Waterpumpswitch.
Testbuttontocheckbothinternalandexternaltemperatureandtosettheclock.
Testbuttontocheckthevoltageoftheleisurebattery(B2)andcarbattery(B1),tocheckcharge
anddischargecurrentsofleisurebatteryandtosettheclock.
andtosettheclock.
Auxiliaryoutputswitch.
Mainswitch(seeminimumvoltagecontrol).
Digitaldisplayoftheclockandoftherequiredtest
2)
8)
18)
Lightsmainswitch.
Itshowsthestartingupofthebatteryparallelwhentheengineisstarted.
Itshowsthecar(B1)batterytest,theblinkingmeansrun-downbatteryalarm.
Itshowstheleisure(B2)batterytest,theblinkingmeansrun-downbatteryalarm.
Itshowsthebatteriesrechargingthroughenginealternator.
Itshowsthetestoralarmofbatteriestogetherwiththesymbols10or11.
Itshowstheconnectiontothe230Vnet.
Itshowsthattheminimalvoltagedevicehasswitchedon.
Itshowsthedrinkwatertanktest,theblinkingmeansemptytankalarm.
Itshowsthewastewatertanktest,theblinkingmeansfullwastewatertankalarm.
Itshowstheunitofmeasure:U=Volt, A=Ampere,°CandtemperaturereferenceI=internal
temperature,E=externaltemperature.
CAPTIONS
NOTE: Thewatchissuppliedfromtheleisurebattery(B2).
ShouldB2bedisconnected,thewatchisabletokeepworking,withoutvisualization,forabout
2weeks.
P C - 2 0 0
%
G
AUX
MOTOR
CAMPERS
G
%
1
2
3
17161513
12
11
10
98
14 18
6
5
4
7
