CBE DS-520AN - Detailed Functions and Battery Management; Battery Recharging and Separation; Broken Fuse Alarm System

CARBATTERY(B1)RECHARGING
LEISUREBATTERY(B2)RECHARGING
ELECTRONICBATTERYSEPARATOR
BROKENFUSEALARM
Whenthebatterychargerischarging,anelectronicdeviceallowsarecharging(max2A)ofthecar
battery(B1),thesystemgivesprioritytotheleisurebattery(B2).
byalternator:throughtheseparatingrelais,whentheengineisstarted. Theengineignition
controlselectronicallyasmallrelaiswhichcontrolstheotherrelais:parallel,fridge,awninglight,etc.
by230Vnet:buffersystemthroughbatterycharger(see" ").
bysolarpanel:throughasolarregulator.
Anelectronicdevice,whichiscontrolledbytheengineignition,switchesonthebatteryparallel
whenthealternatorvoltageisover13.3Vandswitchesitoffwhentheengineignitionisofforthe
voltageisunder12V. Thedeviceisnotworkingwhenthe230Vnetisconnected.
Thisdevicecontrolsalsotheexternallight’srelais,whichworksonlywhentheengineisoff.
UndereachfuseispositionedaredLED.
ThelightingoftheLEDsignalsthatthefuseisbrokenanditisnecessarytoreplaceitwithanother
fusewiththesamevalue. Thealarmisactivatedonlywhenthecontrolpanelisonandtheuser
relatedtothefuseisswitchedon.
NOTE:beforereplacingthefusefindouttheproblemthatdeterminedtheinterventionofthe
protectionandfixit,necessarywiththehelpofspecializedtechnicians.
a)
b)
c)
batterycharger
FUNCTIONS
19
ENGLISH
