SWITCHMODEBATTERYCHARGER “CB510/516”
TheCB510/516switch-modebatterychargerhasbeenexpresslydesignedforthecaravanningand
boatingsectorandcanautomaticallycharge12Vd.c.leadbatteries.
1) withmaximumcurrentuntiltheend-chargevoltageisreached:
Thebatterychargerisprotectedagainstovertemperatureandthe12Vd.c.outputsareprotectedagainst
shortcircuitandpolarityinversion.
Thechargingsystemiscarriedoutin4stages:
2)whenthe thresholdisreachedthechargercontinuestooperatefor90minutes(lead
batteries)or8hours(gelbatteries)withconstantvoltage.
3) voltageholding13.8Vd.c.(gelbatteries)or13.5Vd.c.(leadbatteries)
4) After10hours,thebatterychargerreachesthe modeandbeginstooperateagainonly
whenthebatteryvoltageislowerthan13Vd.c.
Thehighfrequencyswitchingtechnologyallowstohavehighperformanceswithsmalldimensionsand
limitedweight.
batterycharging
Note:theend-chargevoltageisreachedonlyifthebatteryisefficient.
end-charge
Constant
stand-by
CONNECTIONS
1
2
Pb/Gel
Battery
230Va.c.On/Off
Fuse230Va.c.
F2-2A
15A
25A
F1
CB510
CB516
S-
+
1) +12Vd.c.supply
2) -12Vd.c.supply
3) N.C.
4) Netsignal(+12Vd.c.)
1) Masse
2) Neutral
3) Line
N L
-Technicaldataareindicatedalsointhelabelinsidethecover-
12Vd.c.CONNECTION
1
WHITE
230Va.c.CONNECTION
2
WHITE
