CONNECTION
Theequipmentissuppliedcompletewithconnectioncablesofapprox.50cm.
Carefullyobservethevoltagerequired(12V),thepolarity(black=negative;red=positive)andconnectthe
detectortoalineprotectedbyafuse(1-3A).
Thewhitecableisanoutput(12Vnegative,max50mA)fortheconnectionoftheexternalbuzzer.
INSTALLATION
Itisadvisablethattheinstallationiscarriedoutbyqualifiedtechnicalpersonnelonly,astheincorrect
positioningofthesensormayhamperitscorrectfunctioningandthereforejeopardizethehealthofpeople
insidethecompartment.
USE ASLPGDETECTOR
USE ASLPG ANDSOPORIFICGASDETECTOR
Thejumper(rif.1)mustbesetasin"pos.B"
TheLPGisheavierthanairandwillthereforeconcentrateatthebottomofthecompartment;thedetector
shallbeplacetabout20to40cmfromthefloorinordertoguaranteeaneffectivefunctioningintheevent
ofgasleaks.
Thejumper(rif.1)mustbesetasin"pos. A"
Thesoporificgas(whichisoftenusedbyburglars)islighterthanairandwillthereforeconcentrateatthe
topofthecompartment;thedetectorshallbeplacedateye-height,inthesleepingareaofthe
compartment.
Theinstallationnearthekitchenisnotadvisablebecauseofpossibilefalsealarmsduetocookingvapors
Thedetectorcanbebuilt-inorfixedtothewallwiththespacersupplied.
ThemodulecanbecombinedwithotherCBEand Trumamodulestobecompletedwiththeinstallationof
framesofthe"ModularPlates"range.
Wall-fixing
Built-infixing
D=50mm
