FUNCTIONING
Afterhavingturnedthedetectoronwiththefrontbutton(ref.2),thesensor'sheatingprocedurelastsfor
about90secondsandisindicatedbytheyellowled .(ref.3)
Attheendoftheheatingprocedure,thedetectorisreadytosignalanyalarmingsituation. Theoperating
modeisindicatedbytheflashingoftheyellow(ref.3)(1flashevery2seconds).
Whenthegasconcentrationexceedsthelimitestablished,theacoustic(buzzerwithintermittentsound)
andvisual(yellowledalwayson)alarmstartsfunctioning.
Thealarmcontinuestooperateuntilthedetectoristurnedoff.
TECHNICALSPECIFICATIONS
Inputvoltage
Absorbedcurrent,typical
Absorbedcurrent,alarm
Operatingtemperature
Humidity
12 Vdc
10 mA
-10÷40 °C
30÷95%
Heatingtime 90 sec.
Acousticpower 85dBatadistanceof1metrewithexternalbuzzer
12 mA
Detectorlife 10 years
Dimensions (mm) 60x60x20 max
