Chapter 4 Interface
4.1 USB Interface
1.USB (Type A)
PIN
SIGNAL NAME
1 VBUS
2
D-
3
D+
4 GND
2.USB (Type B)
PIN SIGNAL NAME
1
VBUS
2 D-
3
D+
4 GND
