15
Supported Protocol Platforms
16
Supported Protocol Platforms
Application Dependent Configuration Parameters
During programming, the provided CNACONFIG utility allows the user
to select from one of the available pre-assigned application
configurations. In the CNACONFIG utility, the Platform menu is used
to select one of the pre-programmed configurations. The following
applications are presently available under the Platform menu:
CNA1001
Application: Genisys to HP1 Protocol Conversion
Communications Port Assignments:
J2-B = unused
J2-C = Genisys
Baud Rate: 1200, 2400, 4800, or 9600
Default = 9600 baud; 8/N/1
J4-A = unused
J4-B = HP1
Clock Rate: 1200, 2400, 4800, or 9600
Default = 9600 baud
ENET-LAN = Configuration and debug only
CNA1003
Application: Genisys to IP network adapter
Communications Port Assignments:
J2-B = unused
J2-C = Genisys
Baud Rate: 1200, 2400, 4800, or 9600
Default = 9600 baud; 8/N/1
J4-A = virtual terminal 1
J4-B = unused
ENET-LAN = Configuration and debug only
Application Dependent Configuration Parameters (cont.)
CNA1004
Application: Base Station to IP Network Adapter
Infrastructures: ARES / ATCS / GTC (ARES networks)
Communications Port Assignments:
J2-B = virtual terminal 1
J2-C = ARES Async serial port;
Baud Rate: 1200, 2400, 4800, 9600, 19200, 38400,
57600, or 115200
Default = 9600 baud; 8/N/1
Not used in ATCS mode
J4-A = virtual terminal 2
J4-B = HDLC Sync serial port to base stations;
Sync Clock: External / Internal 1200, 2400, 4800, 9600,
19200, 38400, 57600, or 115200
Default = 9600 Hz, Internal
ENET-LAN = FEPHUB communications on UDP port 5361
Provides logic to monitor external PTT control lines through the
isolated I/O and initiate a reboot upon detection of failure condition
CNA1005
Application: Genisys to S2 Protocol Conversion
Communications Port Assignments:
J2-B = unused
J2-C = Genisys Field; RS232 Async
Baud Rate: 1200, 2400, 4800, 9600, 19200, 38400,
57600, or 115200
Default Settings = 9600 baud; 8/N/1
J4-A = unused
J4-B = S2 Office communications port
Clock: External / Internal 1200, 2400, 4800, 9600, 19200,
38400, 57600, or 115200
Default = 9600 Hz, Internal
ENET-LAN = Configuration and debug only
