A GSM SIM card is to be provided by the user.
Notes on Installation
- Wireless Sensors can be placed within 300 ft distance from the Main Unit if there is no obstruction in between. They
have to be registered in the Main Unit as explained under the heading “Wireless Sensors, Remotes & Panic Keys
Registering/Deletion ”.
The distance between the Main Unit and Wireless sensors would be maximum when there is minimum interference
of concrete walls, electric appliances etc.
- Install the Main Unit in an open & ventilated area so that the signals from different Wireless Sensors are received
properly by the Main Unit. It should be installed at least 0.5 meters from ground. It should be ensured that no liquid
spills over it.
- Do not install the Main Unit near high frequency electric appliance in order to avoid interference of electromagnetic
waves.
Wireless Sensor’s range checking method
Put a wireless Sensor in Traitor mode.
Take the Sensor to maximum distance from BAS and trigger the sensor.
If mild beeps with sensor ID number is shown on BAS display that means the sensor can be installed up to that
distance.
Connections
- There are 2 Connectors provided at the back side of the main unit. One connector is of 10 pins and the other of 20
pins. Their corresponding female connectors with wires are also provided with the system.
- The wires from the female connectors are to be connected as per the tables given below:
20 Pin Connector
Wire Color
To be connected to
Red
Adapter 12V DC +Ve Output.
Violet
External Siren +Ve Wire.
Connect a 9 - 12V DC Type Siren (Max Wattage
300mA). If more than one external Siren is to be
used than install BAS-PS and do the connections as
per the BAS-PS Manual.
Red with Black Sleeving
Auxillary +Ve 8.5 V DC Supply for Sensors.
Sensors that operate 8.5V DC can be connected to
this connector & GND provided the total current
drawn is less than 250mA.
Orange with Black
Sleeving
External PB (Peizo Buzzer) +Ve wire.
Brown
NC Type Wired Zone no 1 wire.
Pink
NC Type Wired Zone no 2 wire.
Orange
NC Type Wired Zone no 3 wire.
Yellow
NC Type Wired Zone no 4 wire.
Green
NC Type Wired Zone no 5 wire.
Blue
NC Type Wired Zone no 6 wire.
White
NC Type Wired Zone no 7 wire.
Grey
NC Type Wired Zone no 8 wire.
Black – 3 Wires
GND – Ve of 12V DC Adapter &
- Ve of Auxillary Output &
- Ve of External Peizo Buzzer &
- Ve of External Siren &
One end of all the Wired Zones wires
10 Pin Connector for “NO Type” Sensors
Wire Color
To be connected to
Brown
NO Type Wired Zone no 1 wire
Red
NO Type Wired Zone no 2 wire
Orange
NO Type Wired Zone no 3 wire
Yellow
NO Type Wired Zone no 4 wire
Green
NO Type Wired Zone no 5 wire
Blue
NO Type Wired Zone no 6 wire
White
NO Type Wired Zone no 7 wire
Grey
NO Type Wired Zone no 8 wire
Black
The other end of all the NO Type Wired Zones Wires
