17
As the colours of the wires in the mains lead of this appliance may not
correspond with the coloured markings identifying the terminals in your
plug, proceed as follows:-
• The wire which is coloured GREEN and YELLOW must be connected
to the terminal which is marked with letter (E) or by the Earth
symbol
or coloured GREEN and YELLOW.
• The wire which is coloured BLUE must be connected to the terminal
which is marked with the letter (N), or coloured BLACK.
• The wire which is coloured BROWN must be connected to the
terminal which is marked with the letter (L) or coloured RED.
If in doubt regarding the electrical connection of this appliance, consult a
qualified electrician. Do not shorten the supply cable, the appliance may
require removing for servicing.
N.B. Ensure that the plug socket is situated in an easily accessible place.
If the power supply cord is damaged, it must replaced by a CDA
authorised agent.
Technical information:
For electrical ratings see plate on rear of machine.
Overall dimensions : 86.5 - 89 cm x 59.5 cm x 53 cm (height x width x depth)
Maximum dry weights: Cotton or linen 7.0 kg
Maximum dry weights: Synthetics 2.0kg.
Fuse rating: 13 A
