CDA FW482 Manual For Installation, Use And Maintenance

5
Control panel
A. Orange Compressor light
This light is illuminated when the compressor is running (for example, when Super Freeze is switched on)
B. Green Power light
This light is illuminated when the power supply to the appliance is on.
C. Red Over Temperature Light
This light is illuminated when the interior temperature is too warm.
D. Thermostat dial
The thermostat can be set between 0 (least cold) and 5 (coldest)
Super Freeze function
Your freezer is equipped with a super freeze function, which runs the compressor continuously. Super freeze should be used
when introducing large amounts of fresh food into the freezer.
To switch the super freeze function on, turn the thermostat dial fully clockwise to SF. When the super freeze function is no longer
required, turn the thermostat dial back to the required setting.
fig. 1
D
!
1
2
3
4
5
SF
0
BA C

CDA FW482 Specifications

General

Brand	CDA
Model	FW482
Category	Freezer
Language	English
