CDA fw852 User Manual

9
Control Panel
A. Refrigerator Button
This button is used to adjust the fridge temperature between 2°C and
10°C in 1°C increments.
To change the temperature setting, press this button once so the
display shows the set temperature and flashes. While it is still flashing,
press this button several times until the required temperature is shown
on the display. Approximately 5 seconds after your last press of this
button the new temperature is set and the display changes back to
showing the actual temperature inside.
After changing the temperature setting the time taken to achieve
the new temperature will depend on how big the change is from the
previous setting.
B. Refrigerator Temperature Display
In normal running this shows the actual temperature in the refrigerator
compartment. See above for how this is used in setting the
refrigerator temperature.
B C D
A
E
Fig. 3

CDA fw852 Specifications

General

Child lock	-
Door hinge	Right
Product color	White
Built-in display	No
Reversible doors	Yes
Shelves material	Glass
Appliance placement	Built-in
Refrigerating medium	R600a
Fridge door balconies	3
Refrigerating medium weight	61 g
Fridge number of shelves/baskets	5
Noise level	39 dB
Climate class	SN-ST
Total net capacity	244 L
Fridge net capacity	154 L
Fridge gross capacity	159 L
Lamp type	LED
Number of vegetable drawers	2
Star rating	4*
Freezer position	Bottom-placed
Freezing capacity	4.5 kg/24h
Freezer net capacity	81 L
Freezer number of shelves/baskets	4
Storage time during power failure	12 h
Cord length	1.8 m
Current	13 A
Connected load	- W
Power plug type	Type G
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Annual energy consumption	272 kWh
Country of origin	China
Total gross capacity	252 L
Freezer gross capacity	93 L
Package width	573 mm
Package height	1840 mm

Weight and Dimensions

Width	540 mm
Height	1772 mm
Installation compartment depth	550 mm
Installation compartment width	560 mm
Installation compartment height	1785 mm
