2. Move the decor door in or out, as required; this gives an adjustment
of approximately 3mm. The lower decor brackets are slotted to
allow alignment of the decor at the bottom.
Fig. 22
Y
Fig. 23
X
Z
Fig. 24
3. When you are happy with the
position of the decor door and
all lower decor bracket screws
are tight, fit the lower decor
bracket trims (Fig. 24).
Fill any unwanted screw holes
with the remaining cover caps in
one of the polythene bags and
refit any remaining trims.
