11
fig. 6
Reversing the Door
It is possible to reverse the door on this appliance, if required.
To do so, follow the steps below:
1. Remove the glass door by removing the eight screws (3 and
4 in figure 6). Support the door as you do this to prevent
damage.
2. Gently remove the door and place on a padded surface to
avoid the risk of damage.
3. Unscrew the roller (2) and relocate it on the opposite side.
4. Rotate the door 180º and relocate it on the opposite side.
5. Refit the eight screws (3 and 4), ensuring the door is level.
Table of parts
1. Roller fixing screw
2. Roller
3. Hinge fixing screws
4. Hinge fixing screws
