Table for the choice of the injectors
INCREASE OF AIR NECESSARY FOR GAS COMBUSTION (2 m
3
/h x kW)
BURNERS Air necessary for combustion [m
3
/h]
Auxiliary (A) 2,00
Semi-rapid (SR) 3,50
Rapid (R) 6,00
Triple-ring (TR) 7,00
Oven 12,40
Grill 9,30
GB
Cat: II 2H3+
*
= Reference value
BURNERS
Nominal
Power
[kW]
Reduced
Power
[kW]
G 30
-
28-30 mbar
G 31 - 37 mbar
G 20
20 mbar
Ø
injector
[1/100 mm]
Ring
opening
[mm]
Ø
injector
[1/100 mm]
Ring
opening
[mm]
Auxiliary (A) 1,00 0,30 50 - 72 (X) -
Semi-rapid (SR) 1,75 0,45 65 - 97 (Z) -
Rapid (R) 3,00 0,75 85 - 115 (Y) -
Triple ring (TR) 3,50 1,50 95 - 135 (T) -
Oven 6,20 1,30 120 8 * 180 1,5 *
Grill 4,65 - 107 Fully open * 165 3 *
