20
Installation
Important
• Select a level surface that has enough
open space for the intake and outlet
vents (Fig. 2).
• Blocking the intake and/or outlet
openings can damage the oven.
• Place the oven as far away from
radios and TV’s as possible.
Operation of the microwave oven
may cause interference to your radio
or TV reception.
WARNING: Do not install oven over a hob or other heat-producing
appliance. If installed near or over a heat source, the oven could be
damaged and the warranty will be invalidated.
• The rear surface of the appliance must be placed against a wall.
• Leave a minimum clearance of 30cm above the microwave oven.
• A minimum clearance of 20cm is required between the oven and
any adjacent side walls.
• Do not remove the legs from the bottom of the oven.
• The minimum installation height above the floor is 85cm.
FP
FP
FP
PLQFP
FP
Fig. 2
