CDI computorq 3 - Specifications; Display and Measurement Modes; Dimensions and Part Numbers; Operating and Storage Conditions

SPEcIFIcATIONS
DISPLAY - 4-digit LCD, low battery indicator.
SETTING - Displayed with no torque applied.
TRACKING - Real time display with torque applied.
PEAK - Displayed value flashes for 10 seconds at
torque release.
DISPLAY CAPACITY - 8,000 counts CW/CCW torque
from 10% to 125% of full scale.
ACCURACY (72° F)
CW CCW
+/-2% +/-3% of reading, 20% to 100% of full scale
+/-4% +/-6% of reading, 10% to 19% of full scale
DIMENSIONS
PART NUMBER DRIVE LENGTH WEIGHT
2401CI3 1/4” 15 in. 2.0 lbs.
1002CF3 3/8” 17 in. 2.2 lbs.
2503CF3 1/2” 27 in. 3.5 lbs.
SEALED KEY PAD
ON/ZERO - power on - auto self check - zero
UP - (+) increases torque setting
DOWN - (-) decreases torque setting
UNITS - selects ft.lb., in.lb., Nm or kg.cm.
OPERATING TEMPERATURE: 40° to 110° F (5° to 42° C)
STORAGE TEMPERATURE: -1° to 122° F (-20° to 50° C)
HUMIDITY - up to 90% non-condensing
BATTERY - Two (2) “CR123” Lithium cells, over 80 hours
continuous operation.
AUTO SHUT-OFF - Auto power OFF will occur after 2
minutes of non-usage to conserve battery power.
SPEcIFIcATIONS
MODEL 2401CI3 1002CF3 2503CF3
Drive 1/4” 3/8” 1/2”
ft.lb. 2.0 - 20.0 5.0 - 100.0 25 - 250
in.lb. 24 - 240 120 - 1200 300 - 3000
Nm 2.71 - 27.10 13.6 - 135.6 33.8 - 338
kg.cm. 27.6 - 276 138 - 1382 345 - 3456
PLEASE NOTE
1. CALIBRATION - Contact CDI Torque Products for
calibration services.
2. EQUIPMENT REQUIRED - Precision test bars and
certified calibration weights or another torque
source, accurate to 1/2% of reading.
3. NOTES
- If the display shows “Err0” at power on, the
wrench is damaged and must be returned to CDI
Torque Products for repair.
- Remove battery when stored for extended periods.
4. BATTERY REPLACEMENT - Replace with two (2)
“CR123” Lithium cells only (available anywhere).
To replace battery, remove cover on underside of
handle (opposite display).
