Cedar Summit F25630 - Page 100

Hardware
Step 26: Attach Heavy T-Bracket to Fort
A:AttachHeavyT-Bracketto(113)SWWallusing2(WB7)5/16x3”WaferBolts(withatwasherandt-nut).
(g.26.1and26.2)
2 x 5/16 x 3” Wafer Bolt
(5/16” at washer, 5/16” t-nut)
Other Parts
1 x Heavy T-Bracket
WB7
Fig. 26.1
Fig. 26.2
113
113
HeavyT-Bracket
5/16”Flat
Washer
5/16”T-nut
Swing Side Wall
WB7
