Cedar Summit F25630 - Page 102

1 x SW Block Angle FSC 2-1/2 x 3 x 15”
1 x Block SW FSC 2-1/2 x 3 x 15”
2 x SW Post FSC 4 x 4 x 105”
Step 28: Swing Post Assembly
Part 1
282
281
280
Note: Keep all bolts from Step 28 series loose
until start of Step 30
A:Place(280)SWBlockAngleontopof(281)
BlockSWandattach2HeavyL-Bracketsontopof
(280)SWBlockAnglefeeding2(G17)3/8x6”Hex
Bolts(with2atwashers,plasticformedwasherand
locknut)throughbothboardsasshowning.28.1
and28.2.
B:Attach3(WB7)5/16x3”WaferBolts(withat
washerandt-nut)toallthreeholesineach(282)SW
Postasshowning.28.3and28.4. IMPORTANT!
MAKE SURE ALL 6 BOLTS ARE ATTACHED TO
MINIMIZE CHECKING OF WOOD.
C:Place(280)SWBlockAngle&(281)BlockSW
assemblyinbetween2(282)SWPost(Heavy
L-Bracketstowardstheoutside).Place1Heavy
G-Bracketonthetop(282)SWPostandattachwith
(G26)3/8x9-1/4”HexBolt(with2atwashersand
1locknut),asshowning.28.5.
2 x 3/8 x 6” Hex Bolt
(3/8” at washer x 2, plastic formed washer & 3/8” lock nut)
1 x 3/8 x 9-1/4” Hex Bolt
(3/8” at washer x 2 & 3/8” lock nut)
6 x 5/16 x 3” Wafer Bolt
(5/16” at washer & 5/16” t-nut)
WB7
G17
Hardware
Wood Parts
G26
Other Parts
2 x Heavy L-Bracket
1 x Heavy G-Bracket
Fig. 28.5
Fig. 28.1
281
3/8”Flat
Washer
3/8”LockNut
Fig. 28.2
Fig. 28.3
Fig. 28.4
G17
280
HeavyL-Bracket
3/8”Flat
Washer
5/16”T-nut
Plastic
Formed
Washer
3/8”Flat
Washer
3/8”LockNut
HeavyL-Bracket
Bottom View
Top View
5/16”Flat
Washer
G26
WB7
282
HeavyG-Bracket
