Cedar Summit F25630 - Page 106

Step 31: Attach Swings
Other Parts
A:Using1ThreadedClipperchain,join1LongSwingChaintoeachsideoftheswingbeltseat.Makesureto
closetheThreadedCliptightlyusinganadjustablewrench.(g.31.1and31.2).
B: Using1ThreadedClipperchain,jointheShortSwingChaintotheAcroBarandAcroHandle.Makesure
toclosetheThreadedCliptightlyusinganadjustablewrench(g.31.2and31.3)
C:AttachtheotherendoftheswingchainstotheQuickClipsattachedtotheswinghangers.(g.31.1)
1 x Acro Bar
2 x Acro Handle
2 x Swing Belt Seat
2 x Short Swing Chain
4 x Long Swing Chain
6 x Threaded Clips
Short
Swing
Chain
QuickClip
SwingSeat
LongSwingChain
ThreadedClip
TightenClipusing
adjustablewrench
ThreadedClips
attachtoseatand
Acrobar.
SwingSeat
ChainLink
AcroBar
AcroHandles
Fig. 31.2
Fig. 31.3
Fig. 31.1
