Step 33: Attach Slide to Fort
Note: Pre-drill all holes using a 1/8” drill bit before installing the pan screws.
A:PlaceSlidecentredintheopeningbetween(081)CrowsnestPosts.(g.33.1and33.2)
B: Attachslidetofortthroughtheoorboardsandinto(080)SlidenestJoistusing3(S7)#12x2”PanScrews.
(g.33.2&33.3)
Fig. 33.3
Fig. 33.1
Hardware
080
Front
Fig. 33.2
S7
S7
FloorBoards
081
3 x #12 x 2” Pan Screw
S7
Other Parts
1 x Slide
Side View
