Cedar Summit F25630 - Page 30

1 x Board Access FSC 1 x 4 x 22-1/8”
1 x Access Rock Bottom FSC 1 x 6 x 22-1/8”
5 x Board Rock A FSC 1 x 6 x 22-1/8”
5 x Board Rock B FSC 1 x 6 x 22-1/8”
Step 2: Access Ladder / Rockwall Assembly
Part 3
Fig. 2.7
Fig. 2.8
Wood Parts Hardware Other Parts
1 x EN71 Hand Rail
026
029
028
027
H:Place(026)BoardAccessattopoftheassemblyand(027)AccessRockBottomatthebottomofthe
assemblyasshowning.2.7.Thenplace(028)BoardRockAand(029)BoardRockBasshowning.2.7.Do
notscrewboardsdownyet.Rockholesaretobestaggeredsotheydonotformastraightlineandareatthetop
oftheboards.Note: Rock Boards are to be ush to (021) Right Access Rail and (024) Rock Rail. (g. 2.7)
I:Makesureallboardsttogethersnuglyandtheassemblyissquare,thenattach(026)BoardAccessand(027)
AccessRockBottomusing4(S20)#8x1-3/8”WoodScrewsperboard.(g.2.7and2.8)
J:Fastenalltheotherboardswith4(S20)#8x1-3/8”WoodScrewsperboard.(g.2.7)
K:PlaceEN71HandRail1”fromfrontedgeof(025)TopLadderandon(020)LeftAccessRail.Pre-drill holes
using a 3/16” drill bitthenattachEN71HandRailusing2(WL3)1/4x1-3/8”WaferLags(withatwasher).(g.
2.7and2.9)
48 x #8 x 1-3/8” Wood Screw
2 x 1/4 x 1-3/8” Wafer Lag
(1/4” at washer)
WL3
S20
029
028
026
Fig. 2.9
Rock Boards are
ush to each rail
Install these 2
boards rst to
get spacing
IMPORTANT!
Follow hole
pattern
025
WL3
WL3
028
028
028
028
029
029
029
029
S20
Pre-drill
3/16”Bit
x24
x24
1/4”Flat
Washer
020
EN71
HandRail
S20
027
1”
