Cedar Summit F25630 - Page 31

Step 2: Access Ladder / Rockwall Assembly
Part 4
10 x 1/4 x 1-1/4 Pan Bolt
(1/4” lock washer, 3/16” at washer & 1/4” barrel nut)
10 x #8 x 1” Pan Screw
PB2
Hardware
Other Parts
10 x Rocks (green/yellow/burgundy)
S10
L:Alternatingcoloursandshapes,attach1rocktoeachrockboardusing1(PB2)1/4x1-1/4”Panbolt(with
lockwasher,atwasherandbarrelnut)and1(S10)#8x1”PanScrewperrock.(g.2.10and2.11)
ThePanScrewisplacedintheholebeneaththePanBolt.(g.2.10and2.11)
Note: Make sure all hardware is used to secure each rock properly.
Fig. 2.10
3/16”Flat
Washer
1/4”
BarrelNut
Fig. 2.11
S10
PB2
1/4”Lock
Washer
