Cedar Summit F25630 - Page 32

2 x Narrow Window Panel FSC 1-1/4 x 17 x 103”
Wood Parts Hardware Other Parts
4 x Corner Panel Bracket
030
8 x #12 x 3/4” Pan Screw
S8
Step 3: Door Side Wall Panel Assembly
Part 1
A:Place2(030)NarrowWindowPanelsonthegroundasshowning.3.1and3.2.
B:AttachthebottomCornerPanelBracketsushtothegroovededgeofeachpanelwith2(S8)#12x3/4”Pan
Screwsperbracket,asshowning.3.1,3.2and3.3.
C:Measure51”fromthebottomofeachpanelandattachthetopCornerPanelBracketswith2(S8)#12x3/4”
PanScrewsperbracket.(g.3.1and3.2)
Note: TopofCornerPanelBracketmustsitat51”
Fig. 3.1
Fig. 3.3
CornerPanelBracket
030
Fig. 3.2
Top
Noticethisedge
istightandush
againstcorner.
S8
Bottom
Right
Left
030
51”
Inside View
51”
