Cedar Summit F25630 - Page 33

1 x Door Wall Window Panel FSC 1-1/4 x 38-1/2 x 54-1/8”
Wood Parts
Hardware
031
8 x #12 x 3/4” Pan Screw
Step 3: Door Side Wall Panel Assembly
Part 2
D:Lay(031)DoorWallWindowPanelontheground,thenwithahelperhold1(030)NarrowWindowPanelup
againsttheedgeof(031)DoorWallWindowPanelsothebottomedgesareush.(g.3.4and3.5)
E:AttachbothCornerPanelBracketsto(031)DoorWallWindowPanelwith2(S8)#12x3/4”PanScrewsper
bracket.(g.3.4and3.5)
F:RepeatstepsA&Bforthesecond (030)NarrowWindowPanel.
030
CornerPanelBracket
031
030
Fig. 3.4
Fig. 3.5
S8
NoticeendsareushtoDoor
PanelandNarrowPanels
x2perbracket
S8
031
