Cedar Summit F25630 - Page 34

Step 3: Door Side Wall Panel Assembly
Part 3
031
Fig. 3.6
030
WL5
WL5
Hardware
4 x 1/4 x 2-1/2” Wafer Lag
WL5
90
o
Fig. 3.8
Note: Makesurebothpanelsaresquareandushtoeachother.(g.3.8)
Fig. 3.7
030
G:Pre-drillwitha3/16”drillbit,thenfastenthe(030)NarrowWindowPanelstothe(031)DoorWallWindow
Panelwith2(WL5)1/4x2-1/2”WaferLagsper(030)NarrowWindowPanel.(g.3.6and3.7)
