Cedar Summit F25630 - Page 35

2 x Narrow Window Panel FSC 1-1/4 x 17 x 103”
Wood Parts
030
Hardware
8 x #12 x 3/4” Pan Screw
S8
Step 4: Swing Side Wall Panel Assembly
Part 1
A:Place2(030)NarrowWindowPanelsonthegroundasshowning.4.1and4.2.
B:AttachthebottomCornerPanelBracketsushtothegroovededgeofeachpanelwith2(S8)#12x3/4”Pan
Screwsperbracket,asshowning.4.1,4.2and4.3.
C:Measure97-3/4”fromthebottomofeachpanelandattachthetopCornerPanelBracketswith2(S8)#12x
3/4”PanScrewsperbracket.(g.4.1and4.2)
Note: TopofCornerPanelBracketmustsitat97-3/4”
Fig. 4.1
Fig. 4.3
CornerPanelBracket
030
Fig. 4.2
Top
Bottom
Right
Left
030
S8
973/4”
Other Parts
4 x Corner Panel Bracket
Noticethisedge
istightandush
againstcorner.
Inside View
