Cedar Summit F25630 - Page 36

1 x SW Side Panel FSC 1-1/4 x 38-1/2 x 103”
Wood Parts
040
Hardware
8 x #12 x 3/4” Pan Screw
S8
Step 4: Swing Side Wall Panel Assembly
Part 2
D:Lay(040)SWSidePanelonthegroundthenwithahelperhold1(030)NarrowWindowPanelupagainstthe
edgeof(040)SWSidePanelsothebottomedgesareushandtheCornerPanelBracketisushtothegrooved
edgesof(040)SWSidePanel.(g.4.4and4.5)
E:AttachbothCornerPanelBracketsto(040)SWSidePanelwith2(S8)#12x3/4”PanScrewsperbracket.
(g.4.4and4.5)
F:RepeatstepsA&Bforthesecond (030)NarrowWindowPanel.
Fig. 4.4
CornerPanelBracket
030
Fig. 4.5
S8
030
040
Noticeendsareush
andtighttoSWSide
andNarrowPanels.
