Cedar Summit F25630 - Page 40

A:WithatleasttwohelperslifttheDoorWallAssembly,asshowning.5.1and5.2.
B:WithatleasttwohelperslifttheSwingWallAssemblysoitfacestheDoorWallAssemblyandslideboth
assembliestogethersothe(042)LongWallTiesareushtotheendsofthe(030)NarrowWindowPanelsofthe
DoorWallSide,asshowning.5.3,5.4and5.5.
Fig. 5.2
Door Wall Assembly
Fig. 5.1
Fig. 5.5
Step 5: Join Door Wall and Swing Wall Assemblies
Part 1
Fig. 5.3
Fig. 5.4
Swing Wall Assembly
Flushtothiscorner.
042
