C:Looselyattachboth(041)WallTiesandboth(042)LongWallTiesto(030)NarrowWindowPanelswith2
(WB9)5/16x2-1/8”WaferBolts(withatwasher)perboard,asshowning.5.6,5.7and5.8.
D:Looselyattachboth(043)JoistSidesto(030)NarrowWindowPanelswith2(WB8)5/16x2-3/8”WaferBolts
(withatwasher)perboard,asshowning.5.6and5.7.
Step 5: Join Door Wall and Swing Wall Assemblies
Part 2
8 x 5/16 x 2-1/8” Wafer Bolt
(5/16” at washer)
4 x 5/16 x 2-3/8” Wafer Bolt
(5/16” at washer)
Hardware
Fig. 5.7
030
5/16”Flat
Washer
WB9
Fig. 5.6
Fig. 5.8
Door Wall Side
with5/16”
FlatWasher
with5/16”
FlatWasher
with5/16”
FlatWasher
WB9
Door Side View
042
043
041
030
041
030
WB8
WB9
WB8
WB9
