Cedar Summit F25630 - Page 44

Fig. 6.6
030
Step 6: Front Wall Assembly
Part 3
C:Makesuretheassemblyisonlevelgroundandthatthe(030)NarrowWindowPanelsaresquareandtightto
(060)HalfPaneland(061)TransomPanelFront.
D:Tightenall16WaferBoltsonthefrontsideasshowning.6.6.
030
061
060
TightenallWaferBolts
ofFrontAssembly
