Fig. 7.6
Step 7: Back Wall Assembly
Part 3
C:Makesurethe(030)NarrowWindowPanelsaresquareandtightto(060)HalfPaneland(070)Transom
PanelBack.
D:Tightenall16WaferBoltsonthebacksideasshowning.7.6.
TightenallWafer
BoltsonBackAssembly
070
030
030
