Cedar Summit F25630 - Page 62

Wood Parts
Hardware
Step 10: Crowsnest Assembly
Part 4
E:Flushtothetopofeach(081)CrowsnestPostandtight
to(103)CrowsnestR&L,attach(104)CrowsnestTopwith4
(S15)#8x1-3/4”WoodScrews.(g.10.7and10.8)
F: Frominsidethefortpre-drillwitha1/8”drillbitthen
attacheach(103)CrowsnestR&Lto(030)NarrowPanels
using1150
o
Bracketwith4(S8)#12X3/4”PanScrewsper
side.(g.10.9)
103
104
1 x Crowsnest Top FSC 5/4 x 5 x 30-1/2”
104
4 x #8 x 1-3/4” Wood Screw
8 x #12 x 3/4” Pan Screw
Fig. 10.8
Fig. 10.9
Fig. 10.7
030
103
150Bracket
Other Parts
2 x 150
o
Bracket
o
S15
S8
081
Flushandtight
103
S8
S15
