Hardware
130
SpinChalkSign
Inside Fort View
Step 13: Chalk Wall Assembly
Part 3
E:FrominsidetheassemblyplacetheSpinChalkSignintheopeningbetweentheDoorwallSide(030)Narrow
WindowPaneland(131)ChalkwallUprightsoitsitstighttothetopof(130)ChalkTableTop.(g.13.6)
F:AttachSpinChalkSignto(030)NarrowWindowPaneland(131)ChalkwallUprightwith6(S10)#8x1”Pan
Screws.(g.13.6)
Fig. 13.6
6 x #8 x 1” Pan Screw
S10
030
S10
SigntighttoTableTop.
131
Other Parts
1 x Spin Chalk Sign
