Cedar Summit F25630 - Page 70

1 x Door Bottom FSC 1 x 4 x 35-1/2”
Wood Parts
140
8 x #8 x 1-3/4” Wood Screw
Hardware
S15
Fig. 14.1
031
Step 14: Door Assembly
Part 1
A:Ontheinsideoftheassemblyattach(140)DoorBottomtothebottomof(031)DoorWallWindowPanelwith
8(S15)#8x1-3/4”WoodScrews,asshowning.14.1and14.2.
Fig. 14.2
140
S15
