Cedar Summit F25630 - Page 71

Hardware
Other Parts
1 x Door Handle
1 x Catch Plate
Step 14: Door Assembly
Part 2
B:Ontheinsideof(141)DoorWindowPanel,measure18-1/2”upfromthebottomandattachCatchPlateusing
2(S18)#6x1”WoodScrews.(g.14.3and14.4)
C:Ontheinsideof(141)DoorWindowPanelnexttotheCatchPlateattach1DoorHandleusing2(S13)#6x
5/8”PanScrews.(g.14.3and14.4)
Fig. 14.4
Fig. 14.3
S18
S13
18-1/2”
CatchPlate
DoorHandle
Inside View
141
2 x #6 x 1” Wood Screw
2 x #6 x 5/8” Pan Screw
S18
S13
1 x Door Window Panel FSC 1-1/4 x 16-3/4 x 44-7/16”
Wood Parts
141
 71  support@cedarsummitplay.com
