Hardware
180
Step 16: Attach Floor Joists and Gussets
Part 2
C:Linethe2(160)Joistsuptothepilotholesonthe(102)CrowsnestCentreontheDoorWallSide,maintaining
thedistancebetweenthe2boardsof15”.Thejoistsshouldreston(031)DoorWallWindowPanel.(g.16.3
and16.4)
D:Attachjoiststo(102)CrowsnestCentrewith2(S4)#8x3”WoodScrewsperjoist.(g.16.4)
Fig. 16.3
Fig. 16.4
160
4 x #8 x 3” Wood Screw
S4
S4
15”
160
102
031
Door Wall Side
