Cedar Summit F25630 - Page 77

HardwareWood Parts
202
Step 16: Attach Floor Joists and Gussets
Part 3
E:Tothebottomofeach(160)Joist,ontheDoorWallSide,attach1(161)Gussetwith1(S4)#8x3”Wood
Screwpergusset,asshowning.16.5.
F:Frominsidetheassembly,attach(161)Gussetsto(031)DoorWallWindowPanelwith1(S3)#8x2-1/2”
WoodScrewand1(S15)#8x1-3/4”WoodScrewpergusset.Makesurethegussetsarealignedtothepilot
holes.(g.16.6)
Fig. 16.5
161
Door Wall Side Outside Fort View
2 x Gusset FSC 1-1/4 x 4-1/2 x 8”
161
2 x #8 x 3” Wood Screw
2 x #8 x 1-3/4” Wood Screw
2 x #8 x 2-1/2” Wood Screw
S4
S4
161
S4
160
S15
161
031
Inside Fort View
160
S3
S3
S3
Fig. 16.6
S15
