Cedar Summit F25630 - Page 78

Hardware
2 x Floor FSC 1 x 6 x 38-1/2”
2 x Angle Floor FSC 1 x 6 x 44-3/4”
Wood Parts
171
26 x #8 x 1-3/8” Wood Screw
S20
030
Step 17: Floor Board Assembly
Part 1
A:Place2(170)AngleFloorsonthe(043)JoistSides,(160)Joistsand(080)SlidenestJoist.Theseboards
shouldbetightto(081)CrowsnestPostsand(082)and(083)SlidenestAssembliesRightandLeft.(g.17.1and
17.2)
B:Tighttotheoutsideofeach(170)AngleFloorplace1(171)Floor,asshowning.17.1.Theseboardsshould
betightandushtotheinsidecornerof(030)NarrowWindowPanels.(g.17.2)
C: Attachbothboardstothejoistswith7(S20)#8x1-3/8”WoodScrewsinthe(170)AngleFloorsand6(S20)
#8x1-3/8”WoodScrewsinthe(171)Floors.(g.17.2)
Fig. 17.1
030
S20
Back View Door Side
083
171
171
030
030
Door Wall Side
081
Tight
Tight
082
081
080
043
081
170
160171
170
043
Noticetight
tocorner.
Partsremovedforclarity.
Fig. 17.2
x26
170
Top View
