Cedar Summit F25630 - Page 90

Hardware
C:Fit1(232)TransomSideoneachsideofthegapin(230)FrontRoofPanelsothebottomisushwiththe
bottomofthepanelandthenotchededgeof(232)TransomSidetstighttothepanel,asshowning.23.5and
23.6.
D:Attacheach(232)TransomSideto(230)FrontRoofPanelwith2(S3)#8x2-1/2”WoodScrewsperboard.
(g.23.5and23.7)
Step 23: Roof Assembly
Part 2
Fig. 23.6
Fig. 23.7
Fig. 23.5
232
Wood Screw
230
Flush
S3
232
230
230
232
Tight
4 x #8 x 2-1/2” Wood Screw
2 x Transom Side FSC 1-1/4 x 5-1/4 x 9-1/4”
232
S3
