C:Fromtheoutside,ontheSwingSideWall,attach1RoofSupportAssemblytothetopof(030)Narrow

WindowPanelswith1(S3)#8x2-1/2”WoodScrewperside.(g.24.6and24.7)

Note: Thelongpointof(222)GableBottomshouldbeushtotheoutsidefaceof(030)NarrowWindowPanels.

(g.24.6)

Hardware

Fig. 24.6

Fig. 24.7

Step 24: Attach Roof Support Assembly

Part 3

222

030

RoofSupportAssembly

030

2 x #8 x 2-1/2” Wood Screw

Flushtooutsideface

Swing Side Wall
