Step 15: Counter Assembly
Part 7
K: Place Sink and Stove in the openings of the Counter Assembly then attach 4 Mount Clips with included
hardware to the bottom of the Sink and Stove to secure in place. (g. 15.10 and 15.11)
Important: Use a hand held screw driver and DO NOT over tighten.
Note: To remove the Sink or Stove loosen screw 1/4 turn then twist Mount Clips.
Other Parts
1 x Stove
8 x Mount Clip
Mount Clip
with hardware
Mount
Clip
Sink
Stove
Mount Clip
with hardware
Included
Screw
Fig. 15.10
Fig. 15.11
To Next Page
