Use 2 - #6 x 5/8 Pan Screw to attach to fort
Use 2 - #6 x 5/8 Pan Screw to attach to fort
A: From inside the assembly, centred in the top of the opening of panel as shown in the Fort Guide, above the
counter, attach Utensil Shelf with 2 (S13) #6 x 5/8” Pan Screws as shown in g. 16.1 and 16.2.
B: Attach Pot, Pan and Spatula to the Utensil Shelf. (g. 16.1)
Hardware
Other Parts
1 x Utensil Shelf
1 x Pot
1 x Pan
1 x Spatula
Utensil Shelf
Centred
Step 16: Attach Utensil Shelf
Fig. 16.1
Fig. 16.2
2 x #6 x 5/8” Pan Screw
Panel
Panel
S13
S13
