Using 12- #6 x 5/8" Pan Screws, attach hinges to Door & Fort.
Step 18: Attach Door Assembly to Fort
Hardware
A: In the opening for the door as shown in the Fort Guides, measure 5/8” up from the bottom of the opening and
maximum 5/8” from (2601) Lower Jamb or panel and attach the remaining side of the hinges to (2601) Lower
Jamb or panel using 3 (S13) #6 x 5/8” Pan Screws per hinge. (g. 18.1 and 18.2)
6 x #6 x 5/8” Pan Screw
S13
5/8”
5/8”
2601
S13
Fig. 18.2
Fig. 18.1
Door
Hinge
2601
Panel
Outside View
or
Panel
